Fanuc ArcMate 100iB Robot Arm
Fanuc ArcMate 100iB six-axis arc welding robot with a 6 kg payload, 1,373 mm reach, and ±0.08 mm repeatability. Compact, high-speed, and servo-driven—ideal for MIG, TIG, and plasma welding or light material handling in industrial automation cells.
- Freight delivery in 5-15 business days after your order is confirmed
- Shipping quotes at competitive prices, shown before you pay
- Local pickup available at our Othello, WA warehouse (by appointment)
- 10-day testing period and no restocking fee (see our Returns Policy)
- Support Monday-Friday, 10:00 AM - 4:00 PM
Description
The Fanuc ArcMate 100iB Robot Arm is a six-axis, electric servo-driven industrial robot engineered for high-speed, high-precision arc welding and cutting. Built with a modular, compact construction, it delivers exceptional throughput while remaining accurate enough for pick-and-place and material handling tasks.
- Payload: 6 kg at the faceplate, ideal for welding torches and light tooling
- Reach: 1,373 mm horizontal reach with an 985 mm stroke
- Axes: 6-axis articulated structure for maximum flexibility
- Repeatability: ±0.08 mm for consistent, high-quality results
- Robot Mass: 135 kg
- Mounting: Floor, inverted, wall, or angle mount
Designed specifically for continuous arc welding, the ArcMate 100iB features a slim arm and narrow wrist that reach easily into tight fixtures and part openings without collision risk. Integral utilities route gas, air, and wire-feed cabling through the arm, reducing external dress-pack wear and simplifying setup. Sealed joint construction resists weld spatter, fume, and heat for reliable operation in demanding environments.
Compatible with major welding equipment brands, this robot is a cost-effective solution for MIG, TIG, MAG, and plasma welding workcells, as well as cutting and automated assembly applications.
Additional information
| Weight | 485.02 lbs |
|---|---|
| Dimensions | 59.06 × 43.31 × 51.18 in |
