MAZAK VARIAXIS i-800 5-AXIS

In Stock
Add to wishlist
Request Quote
  • Freight delivery in 5-15 business days after your order is confirmed
  • Shipping quotes at competitive prices, shown before you pay
  • Local pickup available at our Othello, WA warehouse (by appointment)
  • Support Monday-Friday, 10:00 AM - 4:00 PM
Categories: ,

Description

GENERAL INFORMATION

Manufacturer: Mazak

Model: VARIAXIS i-800

Year of Manufacture: 2012

Machine Type: 5-Axis CNC Vertical Machining Center

CNC Control: Mazatrol Matrix 2

Indicated Cutting Hours: 8,820 hours

Machine Weight: Approximately 49,500 lbs

AXIS TRAVELS AND WORK ENVELOPE

X-Axis Travel: 28.74″ (730 mm)

Y-Axis Travel: 33.46″ (850 mm)

Z-Axis Travel: 22.05″ (560 mm)

A-Axis Tilt Range: -120° to +30°

C-Axis Rotation: 360° full contouring

Maximum Workpiece Diameter: 39.37″ (1,000 mm); limited to 28.74″ (730 mm) with the 2-pallet changer

Maximum Workpiece Height: 19.69″ (500 mm)

Maximum Pallet Load: 2,200 lbs (1,000 kg)

SPINDLE AND TOOLING

Spindle Taper: CAT 50

Maximum Spindle Speed: 10,000 RPM

Spindle Motor Power: 50 HP peak / 40 HP continuous

Automatic Tool Changer: 80 positions

Tool Change Time: Approximately 4.3 seconds chip-to-chip

Maximum Tool Weight: 44 lbs (20 kg)

Maximum Tool Length: 16.34″ (415 mm)

Rapid Traverse Rate: 1,654 IPM (42 m/min) on X, Y, and Z axes

INCLUDED EQUIPMENT

Two-pallet system

80-position automatic tool changer

Chip conveyor with integrated coolant filtration

Through-spindle coolant rated at 300 PSI

KEY HIGHLIGHTS

Full 5-axis simultaneous machining capability

CAT 50 spindle for heavy-duty machining

Dual-pallet configuration for improved production efficiency

80-position tool magazine for complex machining operations

Through-spindle coolant system rated at 300 PSI

Chip conveyor with integrated coolant filtration

Previously used for machining 17-4 stainless steel and 6061 aluminum

APPLICATIONS

Precision 5-axis machining

Aerospace and automotive component manufacturing

Complex stainless steel and aluminum parts

Multi-sided machining of large components

Heavy-duty industrial production
