Waukesha L7042GSI
TOSHIBA BTD-110R16 CNC TABLE-TYPE HORIZONTAL BORING MILL
- Freight delivery in 5-15 business days after your order is confirmed
- Shipping quotes at competitive prices, shown before you pay
- Local pickup available at our Othello, WA warehouse (by appointment)
- 10-day testing period and no restocking fee (see our Returns Policy)
- Support Monday-Friday, 10:00 AM - 4:00 PM
Description
GENERAL INFORMATION
Manufacturer: Toshiba
Model: BTD-110R16
Year: 2004
Machine Type: CNC Table-Type Horizontal Boring Mill
CNC Control: TOSNUC 888
Spindle Diameter: 4.3″
Rotary Table Size: 63″ × 55″
Spindle Taper: BT50
Maximum Spindle Speed: 3,000 RPM
Spindle Motor: 40 HP
Automatic Tool Changer: 38 stations
MACHINE TRAVELS
X-Axis: 78.7″
Y-Axis: 59.1″
Z-Axis: 57.1″
W-Axis: 19.7″
B-Axis: 360° rotation with 0.001° indexing increments
EQUIPMENT & FEATURES
TOSNUC 888 CNC control
63″ × 55″ rotary table
BT50 spindle taper
38-station automatic tool changer
Coolant system
Chip conveyor
KEY HIGHLIGHTS
Large-capacity horizontal boring mill with a 4.3″ spindle
Extensive axis travels for machining large workpieces
Rotary table with fine indexing for multi-face machining
40 HP spindle motor and speeds up to 3,000 RPM
BT50 tooling interface and 38-station automatic tool changer
APPLICATIONS
Precision boring and milling of large components
Heavy-duty machining of industrial parts
Multi-face machining of large workpieces
General manufacturing and fabrication applications
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Please contact us for additional information or if you have any questions.
